What is a tempered glass door?
The tempered glass door is a glass door made of tempered glass. The door made of prestressed glass improves the strength and load carrying capacity of the glass by chemical and physical methods, and enhances the wind resistance and heat resistance of the glass itself. Sex, impact, etc. Modern tempered glass doors are beautiful in appearance and diverse in variety, and are the pursuit of individuality and fashion after the 80s. Walking to the street, glass doors can be seen everywhere, and its decorative effect is indeed better than other types of doors; tempered glass doors also have a glass transparent effect, for the home, there is a good decorative effect, for commercial shops , also has a good product display effect.The disadvantage of the larger glass door is that it is fragile. In order to solve the problem of fragility, people have invented the technology of tempered glass and tempered glass, and applied it to the glass door.
After tempering, the strength of the glass is increased, but there will be a self-detonation rate of three thousandths. The annual output of glass doors in China is extremely large, and the number behind the three thousandths is too large. On the other hand, the degree of flatness after tempering Poor will affect the aesthetics of the glass process, and high-end home improvement users will definitely care about this, so the tempered glass door is a kind of risk for the manufacturer is a kind of depression for the user.
The combination of tempering and strengthening is safer and stronger. However, due to the self-explosion rate of tempered glass door glass, it is still not durable. Moreover, the popular 3D ultra-white and mirror process in recent years cannot be tempered before or after the process is completed. Processing, this is currently a major obstacle to the development of glass doors.
(1) Line positioning. Dash the upper and lower metal crosspieces of the glass door leaf, and fix the pin hole plate of the revolving pin and the rotating shaft connecting plate of the floor spring by the wire. The specific operation can be in accordance with the installation instructions of the floor spring product.
(2) Cutting the glass. The mounting dimensions of the glass shall be measured from the bottom of the position at the top and the top of the middle, and the smaller size shall be the cut size of the width of the glass. If the dimensions measured in the upper, middle and lower are the same, the cutting of the glass width should be 3mm~5mm smaller than the measured size, and the height of the glass plate should be cut, which should be less than the measured size of 3mm~5mm. After the glass plate is cut, the four corners should be chamfered, and the chamfer width is 2mm. If you chamfer yourself at the scene, you should hold the fine grinding wheel block for slow grinding operation to prevent collapse and collapse.
(3) The height dimension of the movable fan should be noted when cutting the glass plate, including the installation site where the upper and lower rails are inserted. In general, the height of the glass should be less than about 5 mm of the measurement size to facilitate positioning adjustment during installation.
(4) Height base. The wooden bottom of the stainless steel (or copper) finish can be fixed to the ground by wooden wedges and nails, and then the stainless steel veneer is stuck on the wooden side with the multifunctional glue. If an aluminum alloy square tube is used, it can be fixed to the frame with an aluminum angle, or fixed with a wood screw on the wooden wedge embedded in the ground.
